Pergolinos and verandas

The cassette awning that slides on guides to form a perfectly tensioned canvas cover has several applications, from a pergolino system to an awning covering glass roofs or existing structures known as a veranda type.

Shading structure consisting of an awning with cassette attached to the wall or ceiling with canvas in traction on the side guides, supported from the front by two 100×60 mm section poles joined with a transverse profile of the same section. The canvas traction is constant and is obtained by means of gas springs inside the side guides and Dyneema cable loops. The structure comes standard with motor, according to the proposed types. All screws are stainless steel. All visible components are powder coated. The product is available in 2 versions: ZIP and Slide. The drainage is guaranteed with a minimum inclination of 25%.

Cassette awning with pull fabric, can be installed supported or hung. Ideal for installation as a sunscreen on glass-roofed verandas, existing pergolas or roof glazing. The fabric is in continuous traction thanks to gas springs located inside the guides and Dyneema® cable reels that transmit the traction to the front. The structure is made of powder coated extruded aluminum while the components are made of die-cast aluminum or stainless steel.

Shade canopy with cassette is ideal for mounting on existing structures, with the fabric attached and pulled even laterally by means of steel springs (Zip) or with guides located under the fabric (Slide). The Slide solution allows the return of the guides up to 50 cm per side in relation to the width of the box with the consequent variation of the width of the support points according to the requirements. The tensioning system allows to have a perfectly tensioned fabric in any opening position of the awning.
